Description

Features

• Premium, long-lasting, and high-performance film.
• Smooth, glossy, holographic finish.
• Distinct honeycomb pattern.
• Equipped with air-release channels.
• Resistant to UV, heat, stains, and scratches.
• Eco-friendly, high-grade tint.
• Water and weatherproof.
• Easy to apply and maintain.
• Equipped with a top protective film.
• Acrylic-based, repositionable ultra-clear adhesive.
• Easy to reposition and slide.
• Features air channel paper liner and self-healing technology.

• Structure

  Composed of 4 layers: Top Protected Film, Polymeric Face Film, Acrylic Adhesive, Release Liner

  Specifications

  • Set of 2 Colors: Light black, Clear Transparent Color
  • Size: 32ft(L)x 1.3ft(W)
  • Lifetime: 2 years (Based on vertical exposure).
  • Type: Automotive, architectural, marketing applications, indoor & outdoor.
  • Pattern: Honeycomb.
  • Set Packaging: Roll.
  • Application Method: Dry application provides better results.

  • Video

    Physical Properties

    Classification			Unit		Spec		Remark
    Thickness		Top protected film		um		16um±5		PET
    	Face Film		um		100um±5
    Acrylic Adhesive		um		20um±2		Solvent-based
    Release liner		um		180um±2%		Paper Liner
    Width		–		cm		30 40±0.01%		1.3ft
    Length		–		m		10±1%		32ft
    Surface		–				Glossy

    Physical Performance

    Features			Test Method		Results
    Gloss (60°)			GB 8807		92.3
    VLT					92% (Clear） 81% (Light Black）
    Peel Strength N 25mm			180°		15
    Self-healing Layer Elongation at Break			GB T 1040.1		112
    Face Film Elongation at Break			GB T 1040.1		309.5
    Tear Strength			GB T529		92.7 KN m
    Tensile Strength			GB T 1040.1		21.6 Mpa
    100% Modulus			GB T 1040.1		9.1 Mpa
    Anti-yellowing					ΔE< 1.2
    Adhesive residue					＜3%
    Release force (N 25mm)			paste on steel board, 90° 26℃ and 60%, GB2792		0.16
    Initial tack (g 25mm)			under 24℃ and 26%, GB31125-2014		860
    180° Peel Strength (N 25mm)			10 – 13		12
    Holding power(h)			paste on steel board, hang on by 25mm*25mm*1kg weight under 29℃ and 55%, GB T4851-1998		48H No Peeling
    Aging Test			65℃ and 7 days		No adhesive residue under 20 times wrapping
    Application Temperature					+20℃ to +30℃
    Service Temperature					-50℃ to +110℃
    Recommended Shelf Life			72°F (22°C) and 50% RH		2 year
    Durability					2 year



    Shelf Life

    2 years from date of purchase when stored at 50°F to 80°F (15°C – 25°C) and 45% to 50% relative humidity. The optimum recommended storage conditions are 72°F (22°C) and 50% relative humidity.

    Important Notice

    Information on physical and chemical characteristics and values in this document are based upon tests we believe to be reliable and do not constitute a warranty. They are intended only as a source of information and are given without guarantee and do not constitute a warranty. Purchasers should independently determine, prior to use, the suitability of this material to their specific use. All technical data are subject to change. In case of any ambiguities or differences between the English and foreign versions of this document, the English version shall prevail and lead.

    Warranty, Limited Remedy, And Disclaimer

    Unless an additional warranty is specifically stated on the applicable VinylFrog product packaging or product literature, VinylFrog warrants that each VinylFrog product meets the applicable VinylFrog product specification at the time VinylFrog ships the product.VinylFrog MAKES NO OTHER WARRANTIES OR CONDITIONS, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTY OR CONDITION OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE OR ANY IMPLIED WARRANTY OR CONDITION ARISING OUT OF A COURSE OF DEALING, CUSTOM OR USAGE OF TRADE. If the VinylFrog product does not conform to this warranty, then the sole and exclusive remedy is, at VinylFrog’s option, replacement of the VinylFrog product or refund of the purchase price.

    Limitation Of Liability

    Except where prohibited by law, VinylFrog will not be liable for any loss or damage arising from the VinylFrog product, whether direct, indirect, special, incidental or consequential, regardless of the legal theory asserted, including warranty, contract, negligence or strict liability.

    Additional information

    Size	1.3x32ft
